| AG60 |
|
|
|
MR6 |
MS12
|
MR30 |
 |
Type |
Output speed n2 rpm |
Max.Output torque Mt2 [Nm] |
Transmission- ratio |
Motor- speed n2 [min-1] |
Motoroutput [kW]
ED 60%?? ED100%* |
Automatic- interlock |
Max.limit swich range Output rotation |
AG 60
230/400V
50Hz |
40 |
175 |
69,7:1 |
2800 |
1,1 |
So |
250 |
20 |
330 |
139,5:1 |
2800 |
1,1 |
So |
275 |
13 |
485 |
220,81 |
2800 |
1,1 |
So |
275 |
9,3 |
575 |
302,2:1 |
2800 |
1,1 |
So |
275 |
7 |
600 |
395,2:1 |
2800 |
1,1 |
Ss |
275 |
5 |
600 |
558:1 |
2800 |
1,1 |
Ss |
275 |
3,8 |
600 |
732,4:1 |
2800 |
1,1 |
Sd |
275 |
2,5 |
600 |
558:1 |
1400 |
0,6 |
Ss |
275 |
1,9 |
600 |
732,4:1 |
1400 |
0,6 |
Sd |
275 |
0,9 |
450 |
732,4:1 |
700 |
0,15 |
Sd |
275 |
|
* ath 100% ED (contious duty), cooling is always required
NOTE: at 60Hz, speed will be 20% higher, torque will be from 0 to 20% less |
| Standard |
| 3-phase motor |
| Terminal box |
| Hollow shaft |
| Any transmission ratio |
| Thermal protection |
| IP 54 |
| 1. Stage plastic |
|
|
| Options |
| D.C./A.C. motor |
| Fan blade |
| Axial ventilator |
| Emergency hand crank |
| Stub shaft |
| Spring actuated single disk brake |
| Mounting angle |
| different versions of built-in limit switches |
|
|
|
| |
|
