MR6

Type	Output Speed n_₂ min^{^-1}	Max. Output torque M_{_t2} Nm	Transmission ratio	Automatic interlock	Motor- speed n_₂ min^{^-1}	Motor output kW	DC %	Max. limit switch range Output rotation
MR 6 230/400V 50Hz	100	10,5	27:1	So	2700	0,22	30	275
	80	13	34:1	So	2700	0,22	30	275
	67	15	40:1	So	2700	0,22	30	184
	54	19	50:1	So	2700	0,22	30	184
	34	26	80:1	So	2700	0,22	30	92
	27	33	100:1	So	2700	0,22	30	92
	17	40	160:1	Ss	2700	0,22	30	46
	14	50	200:1	Ss	2700	0,22	30	46
	12	44	224:1	Sd	2700	0,22	30	33
	10	55	280:1	Sd	2700	0,22	30	33
	8	60	160:1	Ss	1300	0,15	30	46
	6	60	224:1	Sd	1300	0,15	30	33
	4,8	60	280:1	Sd	1300	0,15	30	33
	3,6	55	360:1	Sd	1300	0,15	30	21
	2,9	55	450:1	Sd	1300	0,15	30	21

So = No interlock; Ss = static interlock; Sd = dynamic interlock

Standard

3-phase motor

Terminal box

Hollow shaft

Any transmission ratio

Thermal protection

IP 54 Enclosure

Options

D.C/A.C. motor

Potentiometer

Rotational pulse counter

Emergency hand crank

Stub shaft

Single disk spring actuated brake

Special steel hollow shaft 1.4104

Diff. versions of built-in limit switches
